體、蓋、板 |
閥桿 |
密封面 |
墊片 |
填料 |
工作溫度 |
適用介質 |
WCB |
2Cr13 |
13Cr STL 木體材料 With Body Material 尼龍 Nylon |
增強柔性石墨 13Cr/柔性石墨 Enhanced Flexible Graphite 1Cr13/Flexible Graphite 08軟鋼 08 Soft Steal 0Cr18Ni9Ti 0Cr17Ni12Mo2Ti XD550F(T) PTFE |
柔性石墨 增強柔性石墨 Flexible Graphite Enhanced Flexible Graphite SFB/260 SFP/260 PTFE |
≤425 |
水 蒸汽 油品 Water Steam Oil Goods |
WC1 |
38CrMoAl 25Cr2MoV |
≤450 |
||||
WC6 |
≤540 |
|||||
WC9 |
≤570 |
|||||
C5 C12 |
≤540 |
|||||
ZGCr5Mo |
≤200 |
硝酸類 |
||||
ZG1Cr18Ni9Ti |
1Cr18Ni9Ti |
|||||
≤200 |
醋酸類 |
|||||
ZG1Cr18Ni12Mo2Ti |
1Cr18Ni12Mo2Ti |
z941h的型號和參數(shù)及功能介紹主要尺寸
GB 1.6MPa(BTL) |
|||||||||||||||
DN |
50 |
65 |
80 |
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
700 |
800 |
L |
250 |
265 |
280 |
300 |
350 |
400 |
450 |
500 |
550 |
600 |
650 |
700 |
800 |
900 |
1000 |
H (開) |
415 |
450 |
530 |
620 |
850 |
1035 |
1245 |
1450 |
1475 |
1885 |
2010 |
2180 |
2345 |
2700 |
2850 |
H1(配DZW) |
620 |
715 |
765 |
840 |
875 |
1015 |
1135 |
1375 |
1485 |
1890 |
1990 |
2040 |
2285 |
2345 |
2680 |
D0 |
240 |
240 |
280 |
300 |
350 |
400 |
450 |
500 |
500 |
600 |
700 |
750 |
800 |
850 |
950 |
Wt/(Kg) |
22 |
30 |
44 |
47 |
96 |
160 |
228 |
300 |
388 |
566 |
900 |
1195 |
1450 |
2100 |
2620 |
GB 2.5MPa | |||||||||||||
DN | 50 | 65 | 80 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 |
L | 250 | 265 | 280 | 300 | 350 | 400 | 450 | 500 | 550 | 600 | 650 | 700 | 800 |
H (開) | 415 | 450 | 530 | 620 | 850 | 1035 | 1245 | 1450 | 1475 | 1885 | 2010 | 2180 | 2345 |
H1(配DZW) | 620 | 715 | 765 | 840 | 1015 | 1135 | 1375 | 1485 | 1485 |
1920 |
1990 | 2040 | 280 |
D0 | 240 | 240 | 280 | 320 | 400 | 400 | 450 | 500 | 500 | 600 | 700 | 700 | 800 |
Wt(Kg) | 23 | 32 | 46 | 67 | 112 | 218 | 290 | 324 | 430 | 650 | 1010 | 1250 | 1525 |
GB 4.0MPa | |||||||||||||
DN | 50 | 65 |
80 |
100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 |
L | 250 | 280 | 310 | 350 | 450 | 550 | 650 | 750 | 850 | 950 | 1050 | 1150 | 1350 |
H (開) | 415 | 450 | 565 | 590 | 885 | 1065 | 1250 | 1530 | 1675 | 1900 | 2060 | 2250 | 2575 |
D0 | 240 | 240 | 280 | 320 | 400 | 500 | 550 | 640 | 640 | 750 | 750 | 800 | 900 |
Wt/RF(Kg) | 28 | 35 | 47 | 68 | 150 | 235 | 374 | 550 | 680 | 905 |
